- Precise addressability
- Air Flow monitoring for all microbore connections
- Single access point for testing and maintenance
- Self Cleaning at predetermined intervals
- Three levels of alarm for each microbore connection
- Variable microbore lengths can be used up to 100m
- Linear aspirator technology
- LED's or 3.5" display for alarm levels
- 7 fully Programmable relays available for fire and fault alarms
- Two general purpose inputs available for configurable actions
- Mobile devices can monitor the detector via the iVESDA app
- Enclosure rated to IP40
- VESDANet compatible
- WiFi, 802.11 b/g/n
- USB Hub Port Configuration
- Convenient Cable Termination bay
- 20,000 events
The Detector constantly draws air into the detectors chamber using built-in aspirator. The incoming air is continuously measured for smoke contamination. When smoke is detected, the detector will initiated its selector rotary valve system to individually sample air from each of the connected microbore connections. Following the this process, , the detector will then select the tube with the highest level of smoke contamination. The detector has three seperate alarm thresholds that can be programmed for Action, Alert and Fire. Each level of alarm will provide an output and also and audio visual alarm
- UL
- ULC
- FDA
- VdS (EN54-20)
- AFNOR
- CE
- UKCA
- CSFM
- FM
- ActivFire (ISO 7240-20)
- BOMBA
- RCM
- CCCF
- VESDA – VER-A40-40-STX
- VESDA – VPS-220-STX-SLV
- VESDA – VPS-250-STX-SLV
- VESDA – VSP-1000
- VESDA – VSP-1001
- VESDA – VSP-1002
- VESDA – VSP-1003
- VESDA – VSP-1004
- VESDA – VSP-980-B
- VESDA – VSP-980-B22
- VESDA – VSP-980-W
- VESDA – VSP-980-W22
- VESDA – VSP-981-B
- VESDA – VSP-981-B22
- VESDA – VSP-981-W
- VESDA – VSP-981-W22
- VESDA – VSP-982-B
- VESDA – VSP-982-B22
- VESDA – VSP-982-W22
- VESDA – VSP-983-B
- VESDA – VSP-983-B22
- VESDA – VSP-983-W
- VESDA – VSP-983-W22
- VESDA – VSP-990
- VESDA – VSP-991
- VESDA – VSP-998
- VESDA – VSP-1000
- VESDA – VSP-1005
- VESDA – VSP-1006
- VESDA – VSP-1007
- Hospitals
- Correctional facilities
- Hotels and Restuarants
- Theaters
- Electrical cabinets
- Schools
- Elderly homes
- Warehouses
- Data Centres
- Wind Power Generation
